Proteus SC Hook is a personalised solution designed to elevate the aesthetic and practical quality of any building.

Whether you need flexible panels for aesthetic purposes or to meet specific airflow requirements, our system takes into account live loadings and the extent of perforations sizes needed, with a fully adjustable support system on all axis.

Manufactured with A1 or A2-s1, d0 classified materials.
Mechanical stiffeners ensure stability for larger panels.
Custom perforated & routed patterns available.

Available in flat, curved, corner & soffit configurations.
Wide range of materials & finishes available.
Large format panels available.

DownloadsDownloads Make an EnquiryMake an Enquiry

With the Proteus SC Hook System, you’re investing in a solution that combines strength, originality, and beauty.

Our Proteus SC Hook panels are backed by the uniquely engineered Proteus system of aluminium carriers and ancillary components. This support system is compatible with any wall construction and, in certain applications, can span between structural floors, eliminating the need for secondary structures. This flexibility ensures that the Proteus SC Hook system can be seamlessly integrated into a variety of architectural designs.

Available in solid or perforated formats, our panels come in an extensive range of metals, colours, textures, and forms, allowing for unmatched customisation and personal creative expression. The versatility of the Proteus SC Hook system makes it ideal for numerous applications, including but not limited to: car parks, plant screens, internal wall coverings etc.

The System

The Proteus SC Hook system combines strength and flexibility, offering endless design possibilities with custom perforations and finishes.

Materials & Finishes

Our Proteus SC Hook screen cladding system is available in a diverse range of materials and finishes, allowing for complete flexibility and design versatility.

PPC Aluminium

Material Width: 1000, 1250, 1500, 2000mm Max Panel Width: 760, 1010, 1260, 1760mm

Aluminium’s clean, modern appearance is elevated with durable powder coatings, available in any RAL colour.

Precoated Aluminium

Material Width: 1250, 1500mm Max Panel Width: 1010, 1260mm

Precoated aluminium provides a contemporary finish with pre-applied colours, combining durability with design flexibility.

Anodised Aluminium

Material Width: 1000, 1250, 1500, 2000mm Max Panel Width: 760, 1010, 1260, 1760mm

Anodising enhances aluminium’s surface, delivering a durable metallic finish that reflects light and shadow beautifully.

Copper

Material Width: 670, 1000mm Max Panel Width: 620, 950mm

Copper’s natural weathering creates a striking patina, evolving from bright metallic tones to rich, earthy hues over time.

Bronze

Material Width: 620, 800, 1000mm Max Panel Width: 570, 750, 950mm

Bronze’s warm sheen matures into deep, lustrous tones, adding character and elegance to any façade.

Brass

Material Width: 670, 1000mm Max Panel Width: 620, 950mm

Brass develops a rich, characterful patina, transitioning from golden hues to darker, more textured finishes.

Zinc

Material Width: 670, 1000mm Max Panel Width: 620, 950mm

Zinc’s self protecting patina ensures a durable, low-maintenance finish that adapts to both classic and modern designs.

Stainless Steel

Material Width: 1250, 1500mm Max Panel Width: 1010, 1260mm

Stainless steel offers exceptional strength and corrosion resistance, with a sleek, reflective finish ideal for modern façades.

Weathering Steel

Material Width: 1000, 1250, 1500mm Max Panel Width: 760, 1010, 1260mm

Weathering steel forms a protective patina over time, providing enhanced corrosion resistance and a bold, industrial look.

Filters

Select Colour

Select Tone

Select Texture & Finish

Black
(LG)

Sargasso
(LG)

Terracotta
(LG)

Olive Green
(LG)

Amthracite
(LG)

Oceon Blue
(LG)

Mushroom
(LG)

Heritage Green
(LG)

Raven
(LG)

Moorland Green
(LG)

Merlin Grey
(LG)

Albatross
(LG)

Load MoreLoad More

Learn More

Explore the Proteus SC Hook cladding system in detail to gain a comprehensive understanding of its design and performance.

Proteus SC Hook panel widths vary by material. Refer to the table below for maximum widths by type.
Precoated Aluminium 1260mm

PPC Aluminium 1760mm

Anodised Aluminium 1760mm

Stainless Steel 1260mm

Weathering Steel 1260mm

Brass 950mm

Bronze 950mm

Copper 950mm

Zinc 950mm
For panel sizes that exceed our standard maximums, please contact our team to discuss bespoke solutions.
While most perforated or solid screens are one-dimensional, Formations allows architects and designers to introduce a second dimension by incorporating concave and convex shapes into the surface. This adds texture and movement, creating depth and dynamic visual interest within the design.
Using advanced computer software, we can transform images, logos, letters, and numbers into custom perforation patterns. These designs can be applied to a single panel or extended across multiple panels to create a larger jigsaw effect across the entire façade. Bespoke perforations give designers and building owners the freedom to make a truly distinctive architectural statement.
Get installation right with hands-on training at our UK Learning Zone, where contractors can build confidence and sharpen their practical skills. In addition to in-person sessions, we provide clear, easy-to-follow installation videos and technical guides, ensuring support is always available, whether you’re on site or planning ahead.

To request installation guides or book a training session, please contact us.

ContactContact UsContact Us
Proteus SC Hook is listed on NBS Source, streamlining specification for architects, contractors, and consultants. With access to comprehensive product data, BIM files, and specification clauses, the system is ready for seamless integration into detailed design packages. This supports a smooth transition from concept to construction, ensuring accurate specification and compliance at every project stage.

Learn MoreLearn More

Downloads

Download the latest product, technical, and business documentation to support your project from start to finish.

Proteus has delivered façade solutions across a diverse range of sectors, from education to infrastructure.

Accreditation

Our accreditations reflect our commitment to quality, safety, and the highest industry standards.

Recladding

Learn about the benefits of recladding and discover how it can enhance your projects sustainability, performance and safety.
